Single Phase and Three Phase Fractional Horsepower Electric Motors
These general purpose fractional horsepower motors have a wide range of applications. Because of their high starting torque, they are particularly well-suited for heavy starting loads. Three Phase TEFC motors are suitable for use with Variable Frequency Drives (VFD). The Single Phase and Three Phase motors can be fitted with C-face (B14) or D-Flange (B5) with or without mounting feet for flexible mounting situations.
Applications
- Pumps
- Farm Equipment
- Business machines
- Compressors
- Fans and blowers
- Air Conditioning equipment
- Conveyors
- Gear reducers
- Tools
- Packaging equipment
Single Phase & Three Phase
- Squirrel cage rotor
- Start capacitor
- NEMA dimensions
- Class ‘B’ insulation (130ºC)
- High starting torque
- Ball Bearings
- Open drip proof (ODP – IP21)
- Totally enclosed fan cooled (TEFC – IP55)
- Color: RAL 7022 (Dark Gray) for TEFC; Munsell N1 (Flat Black) for ODP
- Continuous Duty (S1), 40ºC ambient
- V-ring slingers on both endshields (for TEFC only)
- Designed to operate in any position (for TEFC only)
Single Phase
- Single-phase, II, IV or VI pole, 60Hz
- Voltage: 115/208-230V
- Reversible
Three Phase
- Three-phase, II, IV or VI pole, 60Hz
- Voltage: 115/208-230V
- 5:1 CT/1000 VT for TEFC
- Class I, Division 2 Groups B, C, & D for
- TEFC
